FW-Map Fixed-Wing Mapping UAV

Large-Area Aerial Survey with RTK/PPK Centimetre Accuracy

The FW-Map Fixed-Wing Mapping UAV is a high-endurance platform for large-area surveying and photogrammetry. Fixed-wing cruise delivers 90 minutes of endurance covering up to 60 km per flight, dramatically cutting the cost of mapping townships, mines, farmland and infrastructure corridors. A 42-megapixel survey camera captures sharp nadir imagery, while RTK or post-processed kinematic (PPK) positioning yields centimetre-level accuracy without ground-control points in most sites. Automated take-off and landing, plus one-click flight-planning, let a single surveyor run professional-grade missions. Outputs — orthomosaics, digital elevation models and point clouds — are produced directly in standard mapping software, ready for GIS, BIM and engineering use.

Home > Products > Drone Applications > Drone Surveying > FW-Map Fixed-Wing Mapping UAV

Inquire Now >> Next Products >>

Core Test Parameters & Normal Standard Values

Technical Specifications

Parameter	Value	Note
Max Endurance	90 min	Fixed-wing cruise
Coverage per Flight	Up to 60 km	Large-area efficiency
Survey Camera	42 MP global shutter	High-detail nadir imagery
Positioning	RTK / PPK	Centimetre accuracy (2 cm)
Ground Sample Distance	< 1 cm GSD at 100 m	High-resolution output
Wind Resistance	10 m/s	Survey in moderate wind
Flight Planning	One-click autonomous	Take-off & landing automated
Outputs	Ortho / DEM / point cloud	GIS & BIM ready

Core Operation Parameters

Monitoring Parameter	Standard Normal Range	Alarm Threshold	Monitoring Purpose
GSD Consistency	Within 10 % variation	Alarm if changed	Uniform map resolution
GPS Fix Quality	RTK/PPK-fixed	Float excluded	Accurate georeferencing
Wind Speed Limit	< 10 m/s	Hold when exceeded	Stable imagery capture
Battery SOC	30–100 %	< 20 % auto RTL	Guarantee safe return to base
Route Coverage	No gap in flight lines	Alarm if gap detected	Complete area coverage
